Liquid Ring Vacuum Pump​

Liquid Ring Vacuum Pump

Usually, a liquid ring vacuum pump is used as a rotating positive displacement vacuum pump but it can also be used as a gas compressor compressing gases to pressures above the atmospheric.

As far as function, liquid ring pumps have similarities with a rotary vane pump but differences are crucial for achieving highest reliabilities and trouble-free operation. For instance, a liquid ring vacuum pump is designed with the rotor as being the only moving component. There are no metal-to-metal contact within the pump, no valves, no sliding vanes, no need for lubrication (other than outboard mounted bearings). The water provides the sealing while acting as the compressing media within the pumping chamber.  Compression is isothermal with very little temperature rise during compression, low noise without silencers, low vibration, cool and safe operation.

Applications :-
Inlet Flange
25A JIS B 2290 VF
Nominal Pumping
Speed (m3/h)
50 Hz
22
60 Hz
27
Base Pressure(kPa)*1
2.7
Rotating Speed
(min-1)
50 Hz
2900
60 Hz
3500
Standard Motor Output (kW)
1.5
Refill Water Level (m3/h)*2
0.36
Weight(KG)
With Fully - Enclosed fan
Cooled Indoor - Use motor*3
70
Without Motor
50
Model
W505
WA505*1
W805
WA80S*1
W150S
WA150S*1
W310S
WA310S*1
WB310S*2
W630S
WA630S*1
WB630S*2
Inlet Flange
25A JIS B 2290 VF
40A JIS B 2290 VF
50A JIS B 2290 VF
50A JIS B 2290 VF
80A JIS B 2290 VF
Nominal Pumping Speed (m3/h)
50 Hz
44
70
120
260
630
60 Hz
3500
1750
1750
1750
950
Standard Motor Output (kW)
2.2
3.7
5.5
15
30
Refill Water Level(m3/h)*3
0.48
0.6
0.72
2.1
Weight (kg)
With Fully Enclosed
Fan Cooled
Indoor - Use Motor*4
90
110
160
180
200
220
490
520
540
900
1020
1050
Without Motor
60
80
120
140
140
160
350
380
400
700
730
760
